About the product
- Tiny Spectrum analyzer AURSINC Tinysa spectrum analyzer produced by Hugen with hardware V031 The firmware of the tinySA can be updated for newest firmware version update please refer to tinysa org The version info displayed indicates ESD Protection with a diode to improve stability sensitivity antistatic level and longevity
- Frequency Range The tiny sa spectrum analyzer with two inputs high quality MFHFVHF input for 01MHZ350MHz lesser quality UHF input for 240MHz960MHz Switchable resolution bandpass filters for both ranges between 26kHz and 640kHz The tinysa includes all the components of a traditional heterodyne swept spectrum analyzer with a color display showing 290 scan points covering up to the full low or high frequency range
- Builtin Calibration Signal Generator When not used as Spectrum Analyzer it can be used as Signal Generator MFHFVHF sinus output between 01MHZ350MHz UHF square wave output between 240MHz960MHz Builtin calibration signal generator enables automatic selftest and low input calibration
- PC Control The USB interface realizes the Serial over USB CDC protocol and a large number of commands can be called through the serial interface The commands can be used for measurements or updating internal settings The Windows driver will automatically install upon connecting to a Windows PC The driver for Linux is built into the kernel TinysaAPP is available to control the tinysa and capture its screen
- Package List 1x Tiny Spectrum AnalyzerBulitin 500mah battary 28inch touchsreen 2x 20cm787inch RF Cable 1x USBC Cable 2x SMA Female to Female Connector 1x Touchscreen Pen 1x SMA Telescopic Antenna
